TGLightbox

API Reference

Full documentation

Option	Type	Default	Description
`groupAll`	boolean	false	Merge all matching triggers into a single gallery, regardless of data-tglb value.
`startIndex`	number	0	Which slide to start on when opening.
`preload`	number	2	Number of adjacent slides to preload.
`keyboard`	boolean	true	Enable keyboard navigation (arrows, Escape, +/-, F).
`dragToClose`	boolean	true	Drag down to close on touch devices.
`clickOutsideClose`	boolean	true	Click on overlay to close.
`loop`	boolean	true	Infinite carousel loop.
`wheel`	boolean	true	Mouse wheel to navigate slides.
`zoom`	boolean	false	Enable zoom functionality.
`zoomMax`	number	3	Maximum zoom level.
`zoomStep`	number	0.5	Zoom increment per step.
`toolbar`	boolean	true	Show the toolbar (zoom, fullscreen, close).
`thumbnails`	boolean	false	Show thumbnail strip at the bottom.
`closeButton`	boolean	true	Show the close button in the toolbar.
`fullscreen`	boolean	true	Show the fullscreen button.
`icons`	object	{}	Custom icons for buttons. See Icons tab.
`animationDuration`	number	300	Animation duration in milliseconds.
`mainClass`	string	''	Extra CSS class added to the overlay element.
`on`	object	{}	Event callbacks. See Events tab.

Each slide is defined by a plain object (programmatic API) or by data attributes on the trigger element (declarative API). The properties below apply to individual slides, not the lightbox as a whole.

Property	Data attribute	Type	Description
`src`	`href` or `data-src`	string	URL or selector for the content. Required.
`type`	`data-type`	string	Content type: `image`, `youtube`, `vimeo`, `video`, `iframe`, `inline`, `ajax`. Auto-detected from `src` if omitted.
`caption`	`data-caption`	string	Caption text shown below the slide.
`thumbSrc`	`data-thumb`	string	Thumbnail image URL for the thumbnail strip. Falls back to `src`.
`aspectRatio`	`data-aspect-ratio`	string	Aspect ratio for iframe / YouTube / Vimeo embeds. Accepts `16:9`, `4:3`, `21:9`, `1:1`, or a decimal like `1.7778`. Defaults to `16:9`.
`width`	`data-width`	number \| string	Fixed width for iframe / YouTube / Vimeo embeds. Accepts a pixel number (`900`) or any CSS value (`80vw`). The embed is still height-constrained by the viewport.
`width` / `height`	—	number	Intrinsic pixel dimensions passed to `<img>` and `<video>` elements. Programmatic API only.
`mimeType`	—	string	MIME type hint for HTML5 video, e.g. `video/mp4`. Programmatic API only.

Iframe & embed sizing

YouTube, Vimeo, and iframe slides are sized to fill the viewport while preserving their aspect ratio. Use data-aspect-ratio to change the ratio and data-width to cap the width.

Declarative — data attributes

<!-- 16:9 (default for all embeds) -->
<a href="https://youtube.com/watch?v=ID"
   data-type="youtube"
   data-aspect-ratio="16:9">Watch</a>

<!-- 4:3 for older video -->
<a href="https://vimeo.com/123456"
   data-type="vimeo"
   data-aspect-ratio="4:3">Watch</a>

<!-- Ultra-wide embed -->
<a href="https://example.com"
   data-type="iframe"
   data-aspect-ratio="21:9">Open</a>

<!-- Fixed 900 px wide, 16:9 tall -->
<a href="https://example.com"
   data-type="iframe"
   data-aspect-ratio="16:9"
   data-width="900">Open</a>

Programmatic API

TGLightbox.show([
  // YouTube — 16:9
  { src: 'https://youtube.com/watch?v=ID', type: 'youtube', aspectRatio: '16:9' },

  // Vimeo — 4:3
  { src: 'https://vimeo.com/123456', type: 'vimeo', aspectRatio: '4:3' },

  // iframe — capped at 900 px wide
  { src: 'https://example.com', type: 'iframe', aspectRatio: '16:9', width: 900 },
]);

Accepted aspect-ratio formats

data-aspect-ratio="16:9"    // ratio with colon
data-aspect-ratio="16/9"    // ratio with slash
data-aspect-ratio="1.7778"  // decimal
data-aspect-ratio="1:1"     // square
data-aspect-ratio="21:9"    // ultra-wide / cinematic

Event	Callback Arguments	Description
`onInit`	(instance)	Fired when the instance is created and DOM is ready.
`onOpen`	(instance, slide)	Fired when the lightbox begins opening. Return false to block.
`onOpened`	(instance, slide)	Fired after the open animation completes.
`onChange`	(instance, newSlide, prevSlide)	Fired when slide changes. Return false to block.
`onChanged`	(instance, slide)	Fired after slide change animation completes.
`onLoad`	(instance, slide)	Fired when content finishes loading.
`onError`	(instance, slide, error)	Fired when content fails to load.
`onZoom`	(instance, slide, zoomLevel)	Fired when zoom level changes.
`onClose`	(instance)	Fired when the lightbox begins closing. Return false to block.
`onClosed`	(instance)	Fired after the close animation completes.
`onFullscreen`	(instance, isFullscreen)	Fired when fullscreen is toggled.
`onSwipe`	(instance, direction)	Fired when a swipe gesture is detected.

Event Example

TGLightbox.bind('[data-tglb]', {
  on: {
    open: (instance, slide) => {
      console.log('Opened:', slide.src);
    },
    change: (instance, newSlide, prevSlide) => {
      console.log('Changed to:', newSlide.index);
    },
    close: (instance) => {
      console.log('Closing lightbox');
    },
  },
});

Method	Arguments	Description
`TGLightbox.bind()`	(selector, options)	Bind click handlers to all elements matching the selector.
`TGLightbox.show()`	(slides, options)	Create and open a new lightbox instance programmatically.
`TGLightbox.close()`	()	Close the topmost active instance.
`TGLightbox.destroy()`	()	Destroy all instances and clean up event listeners.
`TGLightbox.getInstance()`	()	Get the topmost active instance reference.
`instance.next()`	()	Navigate to the next slide.
`instance.prev()`	()	Navigate to the previous slide.
`instance.jumpTo()`	(index)	Jump to a specific slide by index.
`instance.close()`	()	Close this instance.
`instance.on()`	(event, handler)	Subscribe to an event on this instance.
`instance.off()`	(event, handler)	Unsubscribe from an event.
`instance.zoomIn()`	()	Zoom in by one step.
`instance.zoomOut()`	()	Zoom out by one step.
`instance.resetZoom()`	()	Reset zoom to 1x.
`instance.toggleFullscreen()`	()	Toggle fullscreen mode.

Every button icon can be customized. Pass a string to the icons option — it can be a CSS class (Font Awesome), raw HTML (image/SVG), or a unicode character.

Font Awesome icons

TGLightbox.bind('[data-tglb]', {
  icons: {
    close: 'fas fa-times',
    prev:  'fas fa-chevron-left',
    next:  'fas fa-chevron-right',
    zoomIn: 'fas fa-search-plus',
    zoomOut: 'fas fa-search-minus',
    fullscreen: 'fas fa-expand',
  },
});

Custom image icons

TGLightbox.bind('[data-tglb]', {
  icons: {
    close: '<img src="icons/close.svg" alt="Close">',
    prev:  '<img src="icons/prev.svg" alt="Previous">',
    next:  '<img src="icons/next.svg" alt="Next">',
  },
});

Unicode / emoji icons

TGLightbox.bind('[data-tglb]', {
  icons: {
    close: '×',
    prev:  '←',
    next:  '→',
    zoomIn: '+',
    zoomOut: '−',
  },
});

Icon Key	Button	Default
`close`	Close button (top right)	× (CSS pseudo-element)
`prev`	Previous arrow (left side)	‹ (CSS pseudo-element)
`next`	Next arrow (right side)	› (CSS pseudo-element)
`zoomIn`	Zoom in button (toolbar)	+ (CSS pseudo-element)
`zoomOut`	Zoom out button (toolbar)	− (CSS pseudo-element)
`fullscreen`	Fullscreen toggle (toolbar)	⤢ (CSS pseudo-element)
`play`	Video play button overlay	▶ (CSS pseudo-element)

All visual properties are controlled via CSS custom properties. Override them in your stylesheet to match your design.

Variable	Default	Description
`--tglb-bg`	rgba(0, 0, 0, 0.92)	Overlay background color
`--tglb-border-radius`	8px	Border radius for content and buttons
`--tglb-toolbar-bg`	rgba(0, 0, 0, 0.6)	Toolbar button background
`--tglb-caption-color`	#fff	Caption text color
`--tglb-caption-bg`	rgba(0, 0, 0, 0.8)	Caption background
`--tglb-caption-font-size`	14px	Caption text size
`--tglb-transition-duration`	0.3s	Animation speed
`--tglb-transition-easing`	cubic-bezier(0.4, 0, 0.2, 1)	Animation timing function
`--tglb-z-index`	9999	Overlay z-index
`--tglb-icon-size`	40px	Toolbar button size
`--tglb-icon-color`	#fff	Icon color
`--tglb-thumb-size`	60px	Thumbnail dimensions
`--tglb-thumb-gap`	6px	Space between thumbnails
`--tglb-thumb-active-border`	#fff	Active thumbnail border color
`--tglb-overlay-blur`	8px	Backdrop blur amount
`--tglb-spinner-color`	rgba(255, 255, 255, 0.8)	Loading spinner color

Custom theme example

:root {
  --tglb-bg: rgba(10, 10, 30, 0.95);
  --tglb-border-radius: 12px;
  --tglb-icon-color: #60a5fa;
  --tglb-caption-bg: rgba(10, 10, 30, 0.8);
  --tglb-thumb-active-border: #60a5fa;
  --tglb-overlay-blur: 12px;
}

Key	Action
`←`	Previous slide
`→`	Next slide
`Escape`	Close lightbox
`+` / `=`	Zoom in
`-`	Zoom out
`0`	Reset zoom
`F`	Toggle fullscreen
